New Energy Saving ACDC Fan with the Industry's leading cooling performance with IP56 Option
June 10, 2022
SANYO DENKI has developed and launched the San Ace 172AD ø172 × 150 × 51 mm ACDC Fan(1) and Splash Proof ACDC Fan that feature the highest airflow and static pressure in the industry.(2)
These fans are suitable for cooling air conditioners, inverters, control panels, and other equipment that requires high cooling performance and low power consumption.
Features of the 172AD 9AD and 9ADW type fan
1. High Airflow and High Static Pressure
These fans deliver a maximum airflow of 236 CFM and a maximum static pressure of 0.78 InchesH2O, both of which are leading in the industry.(2)
2. Low Power Consumption
Power consumption has been reduced by approximately 32% compared with the current model.(3)
Also, the PWM control function enables the control of fan speed, contributing to lowering noise and improving energy efficiency of devices.
3. Wide Operating Voltage Range
These fans have an input voltage range of 100 to 240 VAC, supporting both 100 and 200 VAC systems.
4. Water and Dust Protection
With its IP56-rated protection,(4) the San Ace 172AD Splash Proof ACDC Fan is protected from water and dust. This ensures stable fan operation even in harsh environments.
(1) Fans that operate by internally converting AC power from the grid to DC power.
(2) Based on our own research as of July 14, 2021, conducted among equally-sized water-resistant AC fans on the market.
(3) For San Ace 172 AC Fan (Model 109S301)
(4) The degree of protection (IP code) is defined by IEC 60529 (International Electrotechnical Commission) as follows.
IP56:
・Protection against a level of dust that could hinder operation or impair safety
・Protection against powerful water jets
Specifications of the 172AD 9AD and 9ADW type fan
San Ace 172AD 9AD type ACDC Fan - Dimensions: ø172 × 150 × 51 mm, Mass: 750 g
Lead wire model
| Model no. | Rated voltage |
Operating voltage range |
Rated input |
Rated speed |
Max. airflow | Max. static pressure |
Sound pressure level |
||
|---|---|---|---|---|---|---|---|---|---|
| [V] | [V] | [W] | [min-1] | [m3/min] | [CFM] | [Pa] | [inchH2O] | [dB(A)] | |
| 9AD5701P5H003 | 100 to 240 | 90 to 264 | 17 | 3800 | 6.7 | 236 | 195 | 0.78 | 54 |
Expected life: 40000 hours (L10 life: 90% survival rate for continuous operation in free air at 60˚C, rated voltage)
Terminal model
| Model no. | Rated voltage |
Operating voltage range |
Rated input |
Rated speed |
Max. airflow | Max. static pressure |
Sound pressure level |
||
|---|---|---|---|---|---|---|---|---|---|
| [V] | [V] | [W] | [min-1] | [m3/min] | [CFM] | [Pa] | [inchH2O] | [dB(A)] | |
| 9AD5701P5HT03 | 100 to 240 | 90 to 264 | 17 | 3800 | 6.7 | 236 | 195 | 0.78 | 54 |
Expected life: 40000 hours (L10 life: 90% survival rate for continuous operation in free air at 60˚C, rated voltage)
San Ace 172AD 9ADW type Splash Proof ACDC Fan - Dimensions: ø172 × 150 × 51 mm, Mass: 810 g
Lead wire model
| Model no. | Rated voltage |
Operating voltage range |
Rated input |
Rated speed |
Max. airflow | Max. static pressure |
Sound pressure level |
||
|---|---|---|---|---|---|---|---|---|---|
| [V] | [V] | [W] | [min-1] | [m3/min] | [CFM] | [Pa] | [inchH2O] | [dB(A)] | |
| 9ADW5701P5H003 | 100 to 240 | 90 to 264 | 17 | 3800 | 6.7 | 236 | 195 | 0.78 | 54 |
Expected life: 40000 hours (L10 life: 90% survival rate for continuous operation in indoor free air at 60˚C, rated voltage)
Terminal model
| Model no. | Rated voltage |
Operating voltage range |
Rated input |
Rated speed |
Max. airflow | Max. static pressure |
Sound pressure level |
||
|---|---|---|---|---|---|---|---|---|---|
| [V] | [V] | [W] | [min-1] | [m3/min] | [CFM] | [Pa] | [inchH2O] | [dB(A)] | |
| 9ADW5701P5HT03 | 100 to 240 | 90 to 264 | 17 | 3800 | 6.7 | 236 | 195 | 0.78 | 54 |
Expected life: 40000 hours (L10 life: 90% survival rate for continuous operation in indoor free air at 60˚C, rated voltage)
PDF Catalog of the 172AD 9AD and 9ADW type fan
San Ace 172AD 9AD type ACDC Fan φ172 × 150 × 51 mm
San Ace 172AD 9ADW type Splash Proof ACDC Fan φ172 × 150 × 51 mm
Industrial Applications of the 172AD 9AD and 9ADW fan
- Air conditioners
- Control panels
- Inverter
Release Date
July 14, 2021
Safety Precautions
The information stated in this release is current as of July 14, 2021.
“San Ace” is a trademark of SANYO DENKI CO., LTD.
