SANYO DENKI AMERICA application engineers image
Application Engineers at Technical Center in Torrance, California

SANYO DENKI AMERICA Inc.
TECHNICAL CENTER

468 Amapola Avenue, Torrance, CA 90501 | TEL: (800) 905-7989

SANYO DENKI AMERICA Inc.’s Engineering Lab is located in Torrance, California. Technical services for a wider variety of applications are available domestically in the U.S.

Please contact us through your local Sales Representative for inquiries or to schedule an appointment. Our experienced application engineers provide support at SANYO DENKI AMERICA Technical Center, as well as our sales engineers in the field.

Find your local sales representative or via contact form from below button. We hope to support your project soon.

Find Local Representative

Customer Testimonials

The engineering staff showed me how 3 fans, when configured correctly, would perform better in my chassis than the 4 fans I was purchasing, I got more airflow, less noise and saved money!

A lab full of fans, two Design Engineers and an acoustic chamber, what else could you ask for, thank you Sanyo Denki.

I flew in from Denver with several engineers and two of my chassis. One week later Greg Tamashiro had helped us optimize our designs and increase our airflow, he was a pleasure to work with and very knowledgeable.

We brought one of Sanyo Denki’s competitors fans to their lab to find out who had the quieter fan. Sanyo Denki tested both fans in their semi-anechoic chamber right in front of us. Before you ask, Sanyo Denki fan was not only quieter but also had better sound quality.

Available Equipment at Technical Center

Airflow tester (PQ chamber) Air flow vs. Static pressure Air flow vs. Current Air flow vs. Power Air flow vs. Speed Air flow vs. Efficiency System impedance curves Design/System evaluation	Sound proof room and sound meter Voltage vs. Sound Speed vs. Sound PWM Duty vs. Sound Sound FFT analysis Available under customer’s requested condition
Thermal chamber Temperature related evaluation using thermal chamber High and low temperature performance Custom profiling of temperature curves over time Power ON and OFF of fan inside chamber at required profile timing	3D printer Manufacture and evaluate various option for customer application for better properties results (i.e. airflow, noise reduction, etc.) Feedback prior to customer pre-design process
Vibration analyzer and FFT Analyzer FFT analysis Vibration analysis Noise analysis	Oscilloscope and Others Motor performance check Current, Speed, Waveform, Sensor signal, etc. PWM performance test Temperature rise of the electrical parts and winding test

icon Airflow tester (PQ chamber)

Air flow vs. Static pressure
Air flow vs. Current
Air flow vs. Power
Air flow vs. Speed
Air flow vs. Efficiency
System impedance curves
Design/System evaluation

icon Sound proof room and sound meter

Voltage vs. Sound
Speed vs. Sound
PWM Duty vs. Sound
Sound FFT analysis
Available under customer’s requested condition

icon Thermal chamber

Temperature related evaluation using thermal chamber

High and low temperature performance
Custom profiling of temperature curves over time
Power ON and OFF of fan inside chamber at required profile timing

icon 3D printer

Manufacture and evaluate various option for customer application for better properties results (i.e. airflow, noise reduction, etc.)
Feedback prior to customer pre-design process

icon Vibration analyzer and FFT Analyzer

FFT analysis
Vibration analysis
Noise analysis

icon Oscilloscope and Others

Motor performance check
Current, Speed, Waveform, Sensor signal, etc.
PWM performance test
Temperature rise of the electrical parts and winding test

Support Cases

Technical Center Support Case 01:
Design 3D models and make a comparison of performance with different grille design
	Sanyo Denki America Technical Center has a capability of creating various 3D Models to simulate the performance. Based on customer’s grille design, 3D models of slightly different versions were made to compare the performance, to see which scenario brings the performance. The PQ characteristics were improved by changing the shape of the grille, so the power, sound, etc. can be minimized for the same amount of air flow.

Technical Center Support Case 01:

Design 3D models and make a comparison of performance with different grille design

Sanyo Denki America Technical Center has a capability of creating various 3D Models to simulate the performance.

Based on customer’s grille design, 3D models of slightly different versions were made to compare the performance, to see which scenario brings the performance.

The PQ characteristics were improved by changing the shape of the grille, so the power, sound, etc. can be minimized for the same amount of air flow.

Technical Center Support Case 02:

Selecting the Best Fan in a System

Open PDF　＞

1) Measuring impedance in system.

2) Determine what airflow is required.

3) Layout airflow-static pressure curve onto system impedance.

4) Finalize different fan options.

5) Measuring vibration and sound. (Optional)

6) Additional support.

Technical Center Support Case 03:
Servo Systems - Software Support
	We offer a range of software support services. 1) Programming support. 2) Software debug. 3) Parameter setting. 4) Support selecting the best servo product. 5) Test the customer's program using actual device.

Technical Center Support Case 03:

Servo Systems - Software Support

We offer a range of software support services.

1) Programming support.

2) Software debug.

3) Parameter setting.

4) Support selecting the best servo product.

5) Test the customer's program using actual device.

Technical Center Support Case 04:
Servo Systems - Programming Support
	We provide comprehensive programming support for ensuring smooth integration with customer's systems. Below are some examples. Contact our team for expert support. 1) Pick and Place SCALA Robot programming support for manufacturing site. 2) X-Y-Z gantry programming support for 3D printing applications

Technical Center Support Case 04:

Servo Systems - Programming Support

We provide comprehensive programming support for ensuring smooth integration with customer's systems. Below are some examples. Contact our team for expert support.

1) Pick and Place SCALA Robot programming support for manufacturing site.

2) X-Y-Z gantry programming support for 3D printing applications
