SANYO DENKI High-Performance DC Cooling Fan

SANYO DENKI's High-Performance Cooling Fans are meticulously engineered to deliver optimal cooling performance,

meeting the escalating demands of new technologies. Available in Axial and Counter Rotating Models

Axial: 9HVA, 9HVB Type - Highest Performance Axial Fans

Counter Rotating: 9CRA, 9CRB, 9CRJ Type for even higher static pressure performance

Providing maximum airflow and static pressure specifications

Various PQ Performances to select from
Using three-phase technology for better vibration suppression
All Fan Types come with a PWM Control function to control the fan speed, noise and energy efficiency
Operational Temperature Range: -20C ~ +70C

Specification Comparison

Axial/CR	Fan Type	Frame Size Offerings	Voltage Range	Part Number	MAX. Speed (min-1)	MAX. Airflow (CFM)	MAX. Static Pressure (InchesH2O)
Axial	9HVA	40x28mm	12V	9HVA0412P3J001	38000	37.1	9.24
	9HVA	40x28mm	24V	9HVA0424P3G001	33000	32.5	6.63
	9HVA	60x38mm	12V	9HVA0612P1J001	24800	84.3	8.0
	9HVA	80x38 mm	48V	9HVA0848P1G601	16100	132	5.0
	9HVB	80x38 mm	12V	9HVB0812P1G001	18300	141.3	6.42
Counter-Rotating	9CRA	38x48 mm	12V	9CRA0312P4K03	17600	27.2	2.81
	9CRJ	40x56 mm	12V	9CRJ0412P5J001	36200	37.4	9.64
	9CRA	60x56 mm	12V	9CRA0612P6K001	18300	80.5	4.54
	9CRB	80x80 mm	12V	9CRB0812P8G001	14600	194	4.6

Get in touch with our application engineers for

dedicated fan selection support and customized options.
